TRYLON 5.930.0202.022 2' Standoff Kit 2-3/8" X 36" Pipe with Two Mounting Kits That Work Up to 11" OD Round & 8" Angled Legs.Can Be Used with Up to

TRYLON’s 5.930.0202.022 2 ft light standoff antenna mount is designed for use on all models of SuperTitan towers. It comes complete with all necessary hardware for installation direction to the tower legs. The 5.930.0202.022 features a universal backing kit and is designed to adjust to the taper of the self-supporting tower up to 10 deg. (1 in 6) slope. The mounting pipe measures 2 3/8 in OD x 3 ft and includes brackets for 1 1/2 in…TRYLON’s 5.930.0202.022 2 ft light standoff antenna mount is designed for use on all models of SuperTitan towers. It comes complete with all necessary hardware for installation direction to the tower legs. The 5.930.0202.022 features a universal backing kit and is designed to adjust to the taper of the self-supporting tower up to 10 deg. (1 in 6) slope. The mounting pipe measures 2 3/8 in OD x 3 ft and includes brackets for 1 1/2 in – 11 in OD or 60 deg. and 90 deg. angle legs up to 8 in in size. All parts of the standoff mount are hot-dip galvanized for years of maintenance-free performance.The additional projected area created by the mounts themselves as well as the offset distance both must be taken into consideration for wind load calculations. Read More
