SABRE C30-905-213 LDA Series Anchor Bolt Foundation Materials Section 13.Includes Base Shoes, Anchor Bolts, Templates, and Foundation Design (normal

The Sabre C30-905-213 anchor bolt foundation materials include all of the hardware you'll need to connect a Sabre Series LDA self-supporting tower ending in Section #13 to a set of anchor bolts that have been embedded into a concrete foundation. The LDA Section 13 anchor bolt foundation hardware includes:(3) Base shoe weldments(9) Anchor bolt assemblies(3) Horizontal angles(10) Bolt assemblies(1) Normal soil foundation designAll…The Sabre C30-905-213 anchor bolt foundation materials include all of the hardware you'll need to connect a Sabre Series LDA self-supporting tower ending in Section #13 to a set of anchor bolts that have been embedded into a concrete foundation. The LDA Section 13 anchor bolt foundation hardware includes:(3) Base shoe weldments(9) Anchor bolt assemblies(3) Horizontal angles(10) Bolt assemblies(1) Normal soil foundation designAll parts have been completely hot-dip galvanized for years of worry-free corrosion protection and are guaranteed to be 100% compatible with Section 13 of the Sabre Series LDA all-angle self-supporting tower.These foundation materials are supplied with a concrete design based on presumptive soils (4000 psf "normal") and they may not apply to your particular soil conditions. It is highly recommended that you have a licensed geotechnical firm complete a site survey/soil analysis to make sure you get the right foundation design for your tower's location. Read More
