Genuine Icom Replacement Keypad for Professional Portable Radio
The Icom 8930069490 is an OEM replacement keypad assembly designed for the Icom IC-F3020 portable transceiver. This molded rubber keypad features a complete numeric layout with programmable function keys and DTMF capability, providing all essential radio controls in a durable, weather-resistant design. The keypad includes clearly labeled buttons with alphanumeric characters for frequency entry, DTMF dialing, and radio programming functions.
Key Features
- Genuine Icom OEM Part: Factory original component ensuring perfect fit and reliable tactile response
- Full Numeric Layout: Complete 0-9 keypad plus star (*) and pound (#) keys for DTMF operations
- Four Programmable Keys: P0, P1, P2, and P3 buttons at top for customizable functions
- Alphanumeric Labels: Dual-labeled numeric keys (2ABC, 3DEF, 4GHI, 5JKL, 6MNO, 7PQRS, 8TUV, 9WXYZ) for text entry
- Weather-Resistant Rubber: Durable molded construction resistant to moisture, UV exposure, and temperature extremes
- High-Contrast Legends: White text on black buttons for excellent visibility in all lighting conditions
- Tactile Feedback: Molded button domes provide positive tactile response for reliable operation with or without gloves
Key Functions
- P0, P1, P2, P3 - Programmable Function Keys
- 1-9, 0 - Numeric Entry/DTMF Dialing
- 2-9 - Alpha Entry (ABC through WXYZ)
- * (Star) - Special Functions/Menu Access
- # (Pound) - Enter/Confirm
Compatible Radio Models
- IC-F3020 Portable Transceiver
What's Included
- One (1) Icom 8930069490 Replacement Keypad Assembly
Application and Installation
The keypad is one of the most frequently used components on a portable radio and is subject to continuous wear from daily operation. The IC-F3020 keypad is particularly important as it provides not only basic channel selection but also DTMF dialing capability and alphanumeric entry for radio programming and text messaging functions. Over time, keypads can develop various problems including worn or faded key labels, cracks in the rubber material, loss of tactile response from compressed button domes, contamination from dirt and oils that affects button operation, or complete failure of individual keys.
Signs that replacement is needed include difficulty reading key legends, keys that don't respond consistently, sticky or binding buttons, visible cracking or tearing of the rubber, or keys that have lost their tactile click. A worn keypad can significantly impact radio functionality, making it difficult to change channels, enter frequencies, dial DTMF tones, or access programmable functions.
Replacement is moderately complex and should be performed by experienced radio technicians. The radio housing must be disassembled to access the keypad assembly from the front panel. The old keypad should be carefully removed, and the mounting area must be thoroughly cleaned of any dirt, oils, or adhesive residue. Any contamination left on the circuit board can affect the new keypad's performance or prevent proper electrical contact with the underlying switches.
The new keypad must be properly aligned using the molded alignment features and mounting holes. Precise positioning is critical to ensure all 16 buttons (four programmable keys plus twelve numeric/function keys) are correctly positioned over their corresponding switches on the circuit board. Misalignment will result in non-functional or incorrectly functioning keys. The keypad must sit completely flat against the housing without any wrinkles, folds, or raised areas that could affect button operation or compromise weather sealing.
When the housing is reassembled, all buttons should be tested individually to verify proper operation and tactile response. Test each numeric key, both programmable keys, and special function keys to ensure they activate their intended functions. The keypad is also integral to the radio's weatherproofing, so proper installation is essential for maintaining ingress protection.
This replacement part is essential for maintaining full radio functionality, especially for users who rely on DTMF dialing or frequent channel changes. Regular inspection and timely replacement help prevent field failures during critical communications.
Manufacturer Part Number: 8930069490
Part Type: Keypad Assembly (16-Key Numeric with Programmable Functions)
Material: Molded Rubber/Silicone
Color: Black with White Legends
Layout: 4x4 Grid (4 Programmable + 10 Numeric + 2 Special)
